Function
Controls air flow to double-acting cylinders, enabling bidirectional actuation.
The 3/2 way configuration allows for two positions: directing airflow for extending or retracting the cylinder.
Double-Acting Operation: Provides a balanced flow to both ends of the cylinder, enabling both extension and retraction actions.
Solenoid Actuation: Operates electrically via a solenoid coil to switch between positions, ensuring efficient and reliable control.
Material
Body: Constructed from aluminum alloy for high strength and resistance to wear.
Solenoid Coil: Made with copper wire and resin-coated for enhanced durability and safe operation.
Seals: NBR (Nitrile Butadiene Rubber) seals for reliable performance in demanding pneumatic environments.
Design
3/2 Way Configuration: Offers three ports and two positions, typically Normally Open (NO) or Normally Closed (NC).
Solenoid Actuation: Electrically actuated valve that switches between two air paths, enabling smooth operation of double-acting cylinders.
Compact and Efficient: Designed for integration into space-constrained industrial applications while maintaining high performance.
IP65 Rating: Dust-tight and water-resistant, making it suitable for harsh environments.
Usage
Perfect for double-acting cylinders used in automated machinery, robotics, assembly lines, and material handling systems.
Suitable for industrial applications where precise, bidirectional control of compressed air is necessary.
Seal
Equipped with NBR (Nitrile Butadiene Rubber) seals for leak-proof and reliable operation under standard to medium pressure.
Compatibility
Integrates well with standard pneumatic fittings and compatible control systems for air-driven machines, actuators, and pressure regulators.
Working Pressure
Operates effectively under low to medium pressure ranges, generally between 0.2 MPa to 1.0 MPa (29 psi to 145 psi).
